Detail
APPLICATION
● Polymer filament extrusion and forming performance test.
● Formulation design of plastic filament.
● Optimization and control of process parameters for plastic filament extrusion.
● For extruding single/multi-cavity, multi-spec plastic filament.
● Process optimization, cost control and small-scale production, etc.
PERFORMANCE SPECIFICATION
| Model | SESIH-20/28 | ||
| Applicable materials | PEEK/PPS etc. | ||
| Screw diameter | 20mm | ||
| L/D | 28 | ||
| Screw speed | 0-120rpm | ||
| Line speed | 0-10m/min | ||
| Filament diameter | 1.75mm | ||
| Filament diameter accuracy | ±0.02mm | ||
| Pressure measurement range | 0-50MPa | ||
| Pressure measurement accuracy | 0.5%F.S | ||
| Heating/cooling method | Electric heating / Fan cooling | ||
| Operating temperature | Room temperature-400°C | ||
| Temperature control accuracy | ±1℃ | ||
| Max. output | 2-3kg/h | ||
| Main motor power | 3kW | ||
| Control | SIEMENS PLC | ||
| Working voltage | Three-phase 380VAC±10%,Single-phase 220VAC±10%,50Hz | ||
| Rated power | Approx.9kW | ||
| L x W x H | 2600mm×915mm×1500mm | ||
| Weight | 600kg |
