APPLICATION
Material research and development: used to develop new 3D printing materials, by adjusting the formula and process parameters, studying the extrusion performance, molding effect, and mechanical properties of different materials to meet specific 3D printing needs.
Process research: Study the extrusion process of 3D printed wire, optimize parameters such as temperature, pressure, speed, etc., improve the quality and performance of the wire, and provide technical support for large-scale production.
Small batch production: Meet the small batch needs of 3D printing wires within laboratories or small businesses, reduce procurement costs, and customize wire specifications and performance according to their own needs
Teaching and Research: Used for teaching experiments and research projects in universities, research institutions, etc., to enable students and researchers to understand the production principles and process of 3D printing wires, and to cultivate relevant professional talents.
PERFORMANCE SPECIFICATION
FDCI-25/22 | |
Applicable materials | PP、PE etc. |
Screw diameter | 25mm |
L/D | 28 |
Screw speed | 0-100rpm |
Line speed | 0-10m/min |
Casting Roller | 220mm |
Casting die with | 200mm |
Film width | 150mm (depends on materials) |
Film thickness | 0.02-0.1mm |
Film construction | ABA |
Pressure measurement range &accuracy | 0-50MPa 0.5%F.S |
Heating/cooling method | Electric heating / Fan cooling |
Operating temperature | Room temperature-350°C |
Temperature control accuracy | ±1℃ |
Control | SIEMENS PLC |
Working voltage | Three-phase 380VAC±10%,Single-phase 220VAC±10%,50Hz |
Note: The parameters are subject to change without prior notice.
